Single-Rope Timber Grab

Description:

We are one of largest manufactures in the production of material handling devices in China. We also provide grab buckets for specific purposes. The log grab can be classified into mechanical type and hydraulic type. The mechanical timber grab is driven by excavator bucket cylinder, without adding other hydraulic valve blocks and pipelines. This single wire log grab has advantages of simple structure, convenient operation and low maintenance.

Features:

1. Generally, suitable for large loading operations
2. These single wire log grabs are with 5-25 m3 capacity
3. External structure of the product has been designed in 3D.
4. For the single wired cranes
5. Highly suitable for the installation
6. Easy to use

Single Wire Log Grab:

Parameter:

Crane Lifting Capacity (t)	5	10	15	25
Dead Weight (t)	1.6	3.8	5	6
Covered Area when Closed (m2)	0.78	1.25	1.9	2.4
Multiplication Rate of the Hoister Sling	3	3	3	3
Wire rope diameter φ(mm)	17.5	24	28	28
A (m)	1.4	1.8	2	2
B (m)	2.3	3	3.5	3.9
C (m)	2.33	4	4.8	5.5
D φ(m)	0.2	0.4	0.4	0.5
Use Altitude (m)	8.5	9	11	12
Hoister type to be matched	Cranes with one hoisting drums

Note: We can customize as per your requirements.
